FRAMELESS WALL OF GLASS
Overview
Frameless Glass Door offers excellence in design. With minimalist appeal that is timeless as it is efficient, this frameless glass door combines quality with aesthethic appeal. Not only is this wall of windows enticing to The Frameless Glass Door exemplifies excellence in design. With a minimalist aesthetic that is both timeless and functional, it seamlessly blends quality with visual appeal. This striking wall of glass not only captivates from the outside but also delivers a sleek, sophisticated finish for those within.
Designed without a floor track, the minimalist look is further enhanced, while the integrated logic control system ensures smooth, efficient motorized operation. Our motorized system also helps eliminate occupational health and safety risks associated with manual use, reducing the potential for misuse or damage.
Manual operation is available as an option, depending on the door’s size.
Applications
Suitable for many commercial applications including:Clubs, Shopping Centres, Shopfronts, Entertainment Centres, Restaurants, Sports Complexes
Size
Maximum Height -4000 mm
Specifications
Curtain:
Frameless door panels are manufactured from 10 mm, 12 mm, or 15 mm toughened glass, fitted with slimline aluminium top and bottom rails measuring 118 mm high × 40 mm wide. The rails are interconnected using custom-designed stainless steel hinges, allowing the panels to operate as a free-floating or pivoting frameless system.
The door system can be arranged in three standard configurations:
Pedestrian Door Options:
Option A: Access door located at the stack end.
Option B: Access door positioned opposite the stack.
Option C: No access door, with even-numbered panels stacking only.
Stack Bay:
Each stack bay is custom-fabricated to suit individual project requirements. The split-track design enables panels to glide smoothly along the track path and stack compactly within the bay. As folding occurs exclusively within the stack bay, the system can operate close to adjacent obstructions without compromising performance.
Locking:
The main curtain can be secured to the floor at selected intervals along the length of the door. Access doors are fitted with Lockwood locking mechanisms mounted on patch fittings.
Tracks:
Head track - The track assembly comprises a three-part extruded aluminium profile measuring 125 mm high x 105 mm wide, incorporating both the running track and an integrated pelmet to conceal the door drive. Motorised systems are currently limited to straight track runs only. Manual configurations may accommodate certain curved openings—consult Titan Door Systems for further details.
Floor track - the floor track is custom fabricated to suit the door size from residential alfresco areas to large residential
Operation:
Manual Operation:
Manual operation is available.
Motorised Operation:
Where specified, the system may be fitted with a purpose-designed 24V low-voltage motorisation system. The 24V system can be configured with either a single motor or dual motors, depending on door size, weight, and project requirements, to ensure balanced and controlled operation.
The motorisation system incorporates logic control with built-in radio receiver capability and may be operated via local key switch or remote transmitter. Fire input connections and external control integration can be provided where required.
For auto-closing applications, the installation of PE safety beams is recommended.
Motorised systems are engineered on a project-specific basis. Consultation with Titan Door Systems is required to confirm suitability and configuration.
Brochure
.avif)
.avif)
.jpg)
.png)
.png)
.png)
.png)
.png)
.png)
.png)
Why Titan Door Systems Stands Apart
At Titan, every project is more than a transaction, it’s a long-term partnership built on trust, transparency, and a shared vision for excellence. From your first enquiry to ongoing support, we offer a seamless and considered experience defined by clarity, precision, and an unwavering commitment to detail. Whether you're designing for function, form, or both, we guide you through every stage with care, confidence, and craftsmanship.
1. Consultation and Quoting
It all begins with a conversation. We listen closely, offer expert advice, and provide clear, tailored quoting to ensure your goals are understood and aligned from the outset.
2. Design and Engineering
Our design and engineering teams bring creative insight and technical precision to each project, delivering solutions that are as structurally sound as they are visually refined.
3. The Manufacturing Stage
Our fabrication process reflects a commitment to excellence, with every component crafted using trusted materials and exacting standards.
4. Installation and Tutorial
Our skilled installers ensure every system is fitted with care, followed by a detailed handover to empower your team with full understanding and ease of use.
5. Ongoing Support and Maintenance
Our commitment doesn't end at installation. We provide continued support and maintenance to ensure optimal performance, long-term reliability, and lasting peace of mind.
The Voices Behind Our Reputation
Don’t just take our word for it, hear from those who’ve experienced the difference. From homeowners to respected industry leaders, we take pride in delivering quality, reliability, and craftsmanship that consistently surpasses expectations.
When our glass swing door at our office broke unexpectedly, we needed it fixed fast to keep things running smoothly. The team showed up quickly and handled everything with skill and efficiency. They got the door repaired in no time, and it looks and works perfectly again. Their professionalism and quick response really saved the day for us. Highly recommend their service – reliable, friendly, and got the job done right!
The team has been fantastic to work with across our Bendigo Law Courts and Colac sites. Their work on gates, roller shutters, and counterweight doors has been exceptional, meeting all our operational and security requirements with precision and professionalism. They’ve been responsive, reliable, and easy to work with throughout the process. Their commitment to future servicing across all our sites gives us confidence that our facilities are in safe hands. A dedicated and efficient team we can truly rely on.
Working with Titan on the GMHBA Geelong Stadium project was a seamless experience. Their team delivered exceptional quality in supplying and installing all roller shutters, meeting our expectations and the project's demanding schedule. Titan's professionalism and attention to detail were evident throughout, and we look forward to partnering with them on future projects.
I can’t thank these guys enough for helping me out with my sliding gate emergency! It completely stopped working, and I was freaking out about my property being exposed. I called them, and they were at my place in no time. They knew exactly what they were doing and had it fixed superfast. They were professional but also super easy to deal with. I felt so much relief knowing my property was secure again. Honestly, amazing service – I’d recommend them to anyone!
When our glass swing door at our office broke unexpectedly, we needed it fixed fast to keep things running smoothly. The team showed up quickly and handled everything with skill and efficiency. They got the door repaired in no time, and it looks and works perfectly again. Their professionalism and quick response really saved the day for us. Highly recommend their service – reliable, friendly, and got the job done right!
The team has been fantastic to work with across our Bendigo Law Courts and Colac sites. Their work on gates, roller shutters, and counterweight doors has been exceptional, meeting all our operational and security requirements with precision and professionalism. They’ve been responsive, reliable, and easy to work with throughout the process. Their commitment to future servicing across all our sites gives us confidence that our facilities are in safe hands. A dedicated and efficient team we can truly rely on.
Working with Titan on the GMHBA Geelong Stadium project was a seamless experience. Their team delivered exceptional quality in supplying and installing all roller shutters, meeting our expectations and the project's demanding schedule. Titan's professionalism and attention to detail were evident throughout, and we look forward to partnering with them on future projects.
I can’t thank these guys enough for helping me out with my sliding gate emergency! It completely stopped working, and I was freaking out about my property being exposed. I called them, and they were at my place in no time. They knew exactly what they were doing and had it fixed superfast. They were professional but also super easy to deal with. I felt so much relief knowing my property was secure again. Honestly, amazing service – I’d recommend them to anyone!
Frequently Asked Questions
Have questions about our Frameless Glass Doors? Browse through answers to common queries below, or get in touch with us for more information—our team is always here to provide the assistance you need.
Are frameless glass doors safe to use?
Yes, frameless glass doors are made from tempered glass, which is highly durable and shatter-resistant. In the rare event of breakage, the glass crumbles into small, safe fragments to minimize injury risks.
Can frameless glass doors be customized?
Yes, frameless glass doors can be fully customised to suit your space. From glass finishes and hardware to configurations and seamless motorisation, every detail is tailored to match your aesthetic and performance needs with refined precision.
Do frameless glass doors provide sound insulation?
While frameless glass doors are not as soundproof as solid doors, they do provide good sound insulation when paired with proper seals and high-quality hardware. This makes them suitable for offices and residential areas where noise control is moderate.
Are frameless glass doors suitable for outdoor use?
Yes, frameless glass doors can be used outdoors with the addition of weather-resistant seals, durable finishes, and a drainage floor track. This makes them ideal for patios, balconies, or storefronts where both performance and design are essential.
How do I maintain frameless glass doors?
Maintaining frameless glass doors is simple. Regularly clean the glass with non-abrasive, glass-safe cleaners, and when it comes to ongoing care, our team is here to handle the maintenance for you, ensuring effortless performance year-round.
